Paper Making Machines
We’re a leading export quality machine provider and our brand Micro Star Machines is known and famous for the quality and durability. No matter what we always maintain our standards and we believe this is the best way towards our customers.
We deal with the best quality of Paper Making & Packages machines.
Micro Star Machines provides the best quality Paper Making & Packages machines.
Complete Paper Making Plant
This is a compact paper making plant which great efficiency and reliability. We also have other models and each model can be adjust to your personal requirements.
Waste Paper Breaking Up and Wiping Off Impurity Equipment
D TYPE HYDRA PULPER
The equipment has used “D” shape trough body and out of centre position fukes rotor which is of energy conservation, the waste paper and the rotor will touch more rapidly, the frequency will be higher. Herewith, it will largely reduce the break-up time, in the situation of not increasing the power and capacity, It will improve the productivity. The rotor and the thick liquid plate are higher than the trough bottom plane, a low pressure area will be formed around the rotor, the rough impurity will be coming into the sediment well via heavy dregs orifice in the processing, and the dregs will be vented regularly by the grab.
The MS D type water power pulp kneader generally uses chain conveyor feed, outfitting rope crab machine in order to take out the plastic sack, the rope, the iron wire, twining impurity and so on. This is a recommended rope crab machine model as the 1SJL draft showing, for reducing the fibre to drain .Generally uses the impurity separating machine to process useful impurity in order to recycle the good thick liquid.
Ragger / Twisted rope
STY series drum screen
MS STY series drum screen is rough choosing equipment in the waste paper recycling product line, fixed behind hydra pulper to process the big and heavy impurities which come from the waste paper pulp coming out from the waterpower pulp machine and is to reduce this to ensure the quality.
FFDZ duplex fibre separator
The production is a multi-performance stock preparation, which has broke-up the purification and choosing into one. It is the first election equipment to produce higher and middle grade of paper. It is mainly composed of two parts: First, the breaking part, second, the part of the pressure screening. It has many advantages of compact structure, the exception of impurity effects multi function in one machine.
FDZ series single fibres separator
Fibre separator is pulp screening equipment, which uses the proportion between fibre and impurities to get rid of all kinds of waste paper impurities with separation, choosing combination and relief. The machine has three elementary functions such as, the second relief, light impurity separation, cleaning out the heavy rough waste materials by outfitting the flow of fibre separator; the inferior waste paper will be used. Which can reduce the pre-treatment process and increase the hydraulic pulper production capacit
FXDZ single effect fibre separator
The equipment is an improved type based on Taiwan machine, which uses to further loosing and coarse impurities and separation of the waste paper. It can be used for the main flow or screening tailings of rough processing, matched with hydraulic pulper, avoiding impurities to break-up completely. Thereby, reducing the burden of follow-up equipment, meanwhile the hydraulic pulper will increase sieve aperture.
GGZ series drum pulper
The equipment may directly process various scrap papers without selecting, and single machine may perform continuous break-up and rough screening. It can also carry out chemical de-inking processing at one time, with the characteristic of lowest energy, low break-up rate of impurity and fibre. It can mostly keep textile fibre and the completely remove the plastics and the fabrics in the raw materials without selecting, especially, wet strength paper, that harms peptic matter in the papermaking flow.
GCSZ series vertical super high-density hydra pulper
MS GCSZ series vertical super high-density hydra pulper is one kind of new-brand, more high-effect device developed by our company under the traditional high-density pulper. The bigger overall cast of rotor can be more beneficial for rubbing the fibre. Higher speed can be more beneficial for tearing the fibre. Aligning the lower support can be more effective to make up the defects that the bearings centre between traditional pulper is too small. Therefore, MS GCSZ series vertical super high-density hydra pulper has the advantages of pulping, especially pulping special kind of paper like wet strong paper. When waste paper de-inking, due to higher of pulping consistency, it can effectively improve the same amount of chemical raw materials ratio of the slurry, due to increased efficiency in energy conservation has greatly improved water on the concentration increase per unit area increased the number of fibres, reducing pulp beating presser of single fibre, then more effective protection of the fibre length.
JGSZ series energy conservation hydra pulper
The equipment is the energy conservation products based on the original MS GSZ series stand high thick waterpower pulp machine modified. Uses the unique up-transmission design and the bottom flotation technology, under the precondition of original MS GSZ which is highly effective, fast break-up characteristic , the outfit power will reduce to 50% so that it achieves the energy conservation effect. Non-bearing room and non-packing seal in the bottom, which does not need to vindicate, no need to worry about the water and thick liquid leakage forever. The up-transmission device with the unique water cooling to reduce speed, universal joint, the low rate of malfunction and it is easy to service.
GSZ series vertical high-density hydra pulper
The equipment has the rotor with many spiral leaf blades ,the pulp density can reach over 14%, the running machine may bring the huge textile fibre friction force that pulp flow from down to top and up to down with the thick liquid quality is even. Specially, when uses in de-inking thick liquid, under the friction of the highly concentrated paper pulp fibre force through the chemicals function, which can take off the printing ink effect that rapidly increase from the fibre surface. It is the important equipment to process the each waste paper and de-inking pulp.
2WSZ series double vortexes hydra pulper
The equipment is designed according to the water power whirlpool principle. Compares with the single whirlpool pulper, it will save electricity move than 40%, using double transmission, double knives panel and add the water power shearing force, which will urge the waste paper to accelerate hydration. This machine has the advantages of design reasonable and novel, simple operation.
FZZ series impurity separator
The crash panel adopt P.S Fukesi rotor, the interval may adjust between the rotor and sieve plate. That is the ideal low density continuously crash equipment for waste paper, damages the paper, the commodity pulp board.
WSZ series horizontal type hydra pulper
MS FZ series impurity separator mainly uses to separate light-heavy paper from waste paper and continue to break-up the pulp twice times from the pulp kneader.
The equipment collects break-up, separating light-heavy function in one body, whose structure is compact, the efficiency is high, It may be simply the waste paper processing flow, and enable the equipment continuous working, reduce energy consumption.
Mechanical Pulping Equipment
NBH Middle-density hydraulic pressure disk grinder
This machine can be completely instead of traditional the low-consistency disk refiner and the conical refiner. It has advantages of saving water, the electricity saving, to enhance merits and so on paper physics intensity index. This machine also has the self-absorption function; the absolution supplies the thick liquid pump. The beating density is 6%~12% is suitable in hits the chemical pulp or grinds is high rate half chemical pulp. Not only after it may take the steam boiling, the wash, thick liquid beating equipment, also before may take the paper machine, thin thick liquid the fine thick liquid equipment. Widely is suitable the beating which in the waste paper pulp, the grass class thick liquid, the broad-leaf wood-pulp, the needle wood-pulp and so on each kind of thick liquid plants. Uses the Sweden SKF seeker precision bearing, guarantees the mechanical operation steady reliable and used the newest technology theoretical design the micro section tooth grain to guarantee the thick beating desired effect. Uses the rare earth alloy manufacture the micro section life to be longer.
LYWS series double-wire press filter
LYWS the series double-wire press filter introduces the vanguard technology from the US, after the digestion absorption, develops one successful kind of thick liquid concentration handling equipment, can filter pressing massive Paper pulp continuously. The product uses the high strength material manufacture, has the big handling ability, the high dehydrated efficiency, and the low power consumption, low service life and so on outstanding feature, and widely applies in the paper making profession.
Simultaneously uses the high quality to filter the belt, guarantees filter press’s performance and the quality.The double-wire press filter divides into the gravity dehydration, the pressure dehydration, squeezing dehydrates three steps to carry on the dehydrated concentration the function.
HPDZ High Consistency Refiner
It is suitable for skiving of chemical pulp, semi-chemical mechanical pulp, quenching high -rate pulp and fibreboard materials. Using compulsory feeding system, whether the pulp made of complex trees, material with larger difference or remaining the leftover material after timberprocessing, such as wood parings, sawdust, pulp residue and the quenching reed pieces rice wheat grass, cotton stalks, they are all separated to become quality fibre through its high speed eddy and appropriate mill piece clearance. Specially be applicable for non-polluting and semi-mechanical pulp making of rice wheat grass, cotton stalks, and also be used for other high-consistency pulp beating.
JXJZ double spiral thread rolling machine
For the directly rough pulping of the raw materials such as waste paper, straw and wheat grass, the sugar cane dregs reed, wood pieces, bamboo pieces, cotton stalks, maize stalks, wood paring, sawdust, wood chips, wood, linen, wood branches, shrubs, the raw materials may be treated as velour’s fibres by this machine. It can directly crank out high quality mechanical pulp which is strong absorbing ink, high opacity, and soft smooth. When boiling to soak in advance, it can increase to load ball quantity, shorten boiling time, and reduce quantity of chemicals. In another way, adopting the raw materials of pre-treatment and working in high thickness mill, the full chemical pulp, full chemical blanching pulp ,half chemical-mechanical pulp and cooling method high rate mechanical pulp, which will be cranked out to different standard pulp. Use of this mechanism for mechanical pulp will not have waste water to release in the production process accordingly it achieves cleaning production.
LMZ Coarse Refiner
Mostly used for the mechanical pulp making of Straw raw materials. It can replace traditional-type beating machine. The equipment consists of composite rotor, flying cutter, bottom knife, belt wheel, tank, motor and other components. Working Principle is that the raw materials enters into stirred cage through the stuff orifice, utilizing the reciprocity between flying cutter and bottom knife to extrusion each other, friction will bring thread broom . It can dissolve different degree pulp via adjusting the clearance of flying cutter and bottom knife.
GLSZ double screw rod multi-function pulpers
The double screw rod multi-function pulpers are key equipment in the chemistry pulp making machine processing, collection pulping, blanching, beating, wash in a whole, simplified the technical process. This equipment has the good grinding paste function and the highly effective mixing function under the high consistency can complete the response fully using the pulp friction heat, saves energy, simultaneously this equipment may also apply in the plastic and the food industry.
Screening Purification Equipment
400HK highly effective heavy impurity cleaner
The 400HK highly effective heavy impurity cleaner is developed by New-Ridong machine shop new development kind of highly effective low thick heavy impurity cleaner. The main body material quality has the high quality stainless steel and the wear-resisting nylon and so on for the user free choice, gets down the awl is the wear-resisting ceramic material quality.
This product synthesizes the domestic and foreign newest research results and has many creative designs: The contraction rectangle tangent enters the thick liquid mouth, the cushion separation cone, the arc contraction cone curve, the constant platoon dregs rate awl mouth, the combination collection dregs trough and so on, solved the Heavy tar skim gate textile fibre to drain.
GSCZ double cone high-efficient and high-density cleane
Mainly used for high-thickness separation in the waste water treatment process after hydra pulper pulp, such as sand, book nails, pieces of iron and other heavy impurities. It can also be used for low-enriched pre-screening of the impurity separation to chemical pulp. for the protection of a next process after the screening to relief equipment sieve plate, the stator, grinding so that it can reduce the pressure for low-enriched screening.
The equipment is available in stainless steel, ceramics, wearable materials bottle and manual, automatic relief way.
KSZ vibrating screen
This is used for pulp roughing and purification. the joints, film and other impurities will weed out through Frequency vibration in the rough slurry .the fine pulp will go into a next process. This equipment has advantages of simple structure, easy maintenance, low production cost, higher production efficiency，which is the ideal size screening equipment. The equipment has three types such as, high-frequency vibration-frame, high-frequency self-vibration-type, low frequency self- washing.
1LSZ series rotary-wing screen
Mainly used for the low concentration pulp screening pre-wire in the transportation system. Remove out the fibre ball and other non-fibrous impurities, which is the traditional pre-screening network equipment with high efficiency, self-cleaning, low noise characteristics.
2LSZ series high consistency pressure screen
Mainly used for the high concentration screening of pulping, bleaching and de-inking section, which also can be used for low concentration screening before the paper machine technique has widely applicability. According to the shape of screening impurities to choose hole-shaped sieve plate (move out long, Diamond impurities) and the slit-shaped sieve plate (move out particles shape impurities and emplastic).
3LSZ series inflow pressure screen
Mainly used for pulping system of each kind of paper pulp to screen. Also instead of traditional the rotary-wing screen to pulp screening before the paper machine. which has the advantages of big output ,the low pulse, difficult to block, the low power consumption, long service life and so on.
4LSZ series upflow pressure screen
Widely used in all kinds of rough picking of pulp, choiceness and paper machine screen, belongs to outflow screen. Due to its unique up flow structure and distributary’s design of light-heavy impurities, which has the specially good effect to hold up and move out. So this machine is particularly applicable for the waste book that is sensitive to pectin to regeneration pulp screening of de-inking paper and tissue. Also that is the ideal choiceness equipment for renewable newsprint and other waste paper pulping, chemical pulping.
5LSZ series low pulse pre-wire screen
The equipment is a special filtration machine for paper sizing system. The inner and outer streamline structure, the high-precision adjustable drum and configure inside and outside, reasonable shape, layout, which realizes that low pulse operates to pulp filtration. Pulp fibres, fillers and additives are fully dispersed, the transit capacity improved obviously, which is an ideal front net screen for delivery process flow with the high efficiency and low energy consumption. The machine features is less power than traditional front net screen and energy-saving effect is remarkable.
6LSZ series up flow grading screen
MS 6LSZ series up flow grading screen is the latest generation product with patent technology. It is especially designed for recycled waste paper pulp and fibre grading and screening. It has the functions of both grading the fibre, according to their length, and pulp stock screening. It has the advantages of lower energy consumption, accounting for only less than 1/3 of the traditional grading screen, strong fibre grading power and high efficiency of removal of impurities.
LSZ series centrifugal screen
This product are called the CX screen, belongs to a pressure screen. Mainly used for the screening of all kinds of pulp and before pulp coyness. It has features of high efficiency less leaking of pulp, no sizing, no plug, easy operation and maintenance and so on. Especially, is suitable for the waste corrugated paper pulp that no strict requirement and semi-chemical pulp production.
Rejects separator is popular the various European countries in the last few years in the scrap paper pulping flow tail thick liquid processing special purpose equipment. The use effect is good. This machine has characteristics of high textile fibre rate, and low disposal cost. Mainly uses in the choosing of coarse screening after the fibre separator, duplex fibre separator and the pressure screen, after separation arranges in the tailings not to contain the textile fibre, conforms to the environmental protection emission standard. This product is introduces by Austrian VOITH Corporation, after diligently, already voluntarily developed the manufacture in every way by Our company, is in the manufacture domestically scrap paper pulping flow processes the tail thick liquid the ideal equipment.
Paper Making Machine and Other Equipment
MS BJL two phase flow pulp pump
MS BJL two phase flow slurry pump is designed by adopting the newest two-phase flow theory of china. Conquering the defect of clean water (single flow) theory designed when the pump removes the mixture of solid and liquid (two-phase flow), it has characteristics of high energy efficiency, durable, high concentrations of transportation and so on.
MS GQZ complicated pneumatic scraper
MS GQZ complicated pneumatic scraper, which is our factory to import and absorb foreign advanced technology, is a new style scraper of paper wrinkle and cleaning cylinder to develop and product according to fundamental realities of our country. The structure of this scraper is simple and easy to adjust, making the scraper block to move by cylinder’s driving. It can automatically compensate the defect for the dryer’s surface uneven and cleaning vat halfway , after air cell driving the pressure marks increase the pressure of the scraper about complicate motion, not only fine wrinkles and elliptical, is suit for the high middle low-speed machine to use.
MS YZ series high & middle speed tissue machine
The equipment is mainly used for paper making of the low-quantity, high-end life paper. Cone used to for the new technology of multi-tube into pulp, the pressure wire, SS chip moulds. Pneumatic tire pressure, high pressure line striation Idler, double-breathing dryer, double pneumatic scrapper, pulse pneumatic felt corrector, and Electric tighter. It is ordinary rotary screen papermaking machine alternative products.
Thruster of side stock chest
Energy-saving type thruster for side stock chest
Energy-saving type thrusters
Frame type thruster
Broken paper pulper
Broken paper pulpers uses in the paper industry the paper machine press part, the rolled paper department sub aridly damaging the paper, to damage the paper recycling, to stir dry broken, invests in the pulping system’s papermaking supplementary equipment once more, its characteristic is: The work is continual, the structure is simple, the ease of operation, the efficiency is high, the life is long.
Paper Plastic Separating Machine
MS BZW Sludge-plate making system
MS BZW sludge system board aircraft in the light of my company imported machine-like, on the basis of the repeated appraisals, and numerous tests designed to meet China’s national conditions of sludge-processing equipment. The board machine has successfully resolved the comprehensive development and utilization of recycled paper pollution problems; the waste will be transformed into products, to solve the environmental protection not only in contradiction output, and achieved good economic and environmental benefits. Local production of the wide application of sludge board, to replace the wood on the market today and in the Midu Ban straw pulp, applicable to all types of goods within the board, with all kinds of books are the cover and packaging, and so on.
MS LFSZ paper-plastic separating machine
The factory has advanced technology of paper and plastic, paper, aluminium, plastic separation,and also has manufacturers for clients to visit.
For separating the paper and plastic from the tectorial waste paper and in the processing of waste paper pulp the fibre and plastic will be recycled The recycling fibre and use to make paper the plastic may produce grain It has simple the structure the paper and plastic separating completely characteristics.
Sewage Treatment Equipment
MS DS belt filter press machine
It is Mainly used for pulp material inspissation’s washing and dirty mud dehydration ,which is in four areas, namely gravity dehydration, wedge re-pressure dehydration , involution dehydration, cutting dehydration .instead of the Frame Filter Press and centrifuge inspissation’s machines, That is the ideal equipment of pulp washing and dirty mud dewatering .
MS FSLT series air floatation machine
MS FSLT Series Air Floatation Sewage Machine is of steel structure, its working principle is: with pump the air is feed into the tank and being dissolved under the pressure 0.5 Mpa to be forced dissolved in water, the sudden release of the circumstances, the dissolution The air in the water precipitates to form to a large number of micro-bubble group, the slow rise in the process of absorption of suspension so that the density of suspended solids floating drop, to remove SS and CODcr purposes. This machine is adapted to treat sewage comes from production of petroleum, chemical, paper, leather, printing and dyeing, food, starch, etc.
MS LW series tiny filter machine (Fibre recycling
The equipment is a new development micro porous filter which is absorbed New Zealand perfect technology, aiming at China’s national conditions. Widely applicable to the various necessaries occasions for solid-liquid separation such as life municipal sewage, papermaking, textiles, dyeing and Chemical effluent filtration, especially in the white water treatment of papermaking ,It will achieved the obtruding and recycling purpose.
MS ZSW series place buries the type sanitary sewage handling equipment
Buries the type sanitary sewage handling equipment to use the international advanced biological treatment craft, the collection removes BOD5, COD, NH3-N in a body, has the technical performance stably reliable, the processing effect is good, the investment province, occupies a land area few, maintains merits and so on convenience. The equipment embedment below the surface, the equipment above surface may take the forestation or other land, does not need to construct housing and to heat, the heat preservation. The second-level biology catalytic oxidation processing craft uses the drift type biology catalytic oxidation, its processing effect surpasses complete mixed style or the second-level series complete mixed style biology contact oxidation pond. And cuts the active sludge impoundment volume to be small, adding water archery target compatible, bears the impact load performance to be good, the water leakage water quality is stable, will not have the sludge bulking.
In the pond uses the new elastic three-dimensional padding, the surface area is big, micro organism Yi Guamo, escapes the membrane, under the same organic matter load condition, is high to the organic matter elimination rate, can enhance in the air the oxygen in the water the solubility. The biochemistry pond uses the biological contact oxo-process, its padding’s volume load is quite low, the micro organism is in own oxidized step to break, produces the putty quantity to be few, only needs three months (90 days) above to arrange time putty (or dehydrates filter cake foreign shipment with dung cart suction). This buries the type sanitary sewage handling equipment to deodorize the way to eliminate uses the conventional upper air exhaust, in addition has the soil air sweetening measure. The entire equipment processing system has the completely automatic electric control system and the equipment failure alarm system, the movement safe reliable, usually generally does not need the specialist to manage, only need at the right moment carry on the maintenance and the maintenance to the equipment.
MS FQZ series shallow layer air floatation machine
The new highly effective shallow layer gas floats machine, is Our company according to the overseas newest technology, and unifies our country sewage treatment system’s actual situation, experiments, the use, the improvement through near ten years to become unceasingly, the new highly effective shallow layer gas floats machine and the traditional gas floats machine compares, changes the static state to enter the water – dynamic water leakage for dynamic to enter the water – static state water leakage, causes suspension (SS) vertical to float in the relatively static environment on the water surface, the sewage in purifies in the pond only to need 2-3min, the processing efficiency is extremely high. The domestic more than 20 chemical pulping, half chemical pulp, scrap paper units and so on papermaking factory and chemical, leather making urban sewage, use Our company’s gas to float machine, has attained a designated standard the emissions completely; And unifies uses my factory independently to develop has the international advanced level medicament, the cost reduces greatly, is only the original medication cost 2/3.
MS SWZ whorl concave air float sewage treatment equipment
MS FCZ series air floatation type sewage decontamination Clarifying machine is the latest product which is researched and developed by our company through the introduction of foreign technology. It obtains the Shandong province environmental protection product use approval certificate. The system’s removal rate of COD and BOD, SS is more than 85% and 90% respectively. It has the advantages of low energy cost, high efficiency, economical operation, simple operation, low investment cost, small ground occupation and the others. It is widely used in the industrial sewage and municipal sewage’s reaching Standards treatment in the industries of papermaking, chemical industry, printing and dyeing, oil refining, starch and foodstuff.
MS WYZ advection dissolves was mad that the gas floats
The body of device uses the steel plate knee bend to become, through the channel steel and the angle steel reinforcement is a whole, responded that in the pond disposes the response mixer, and guaranteed that the sewage and the medicament responded fully. The catchments system perforates the catchments by the cloth water pipe.
Releases head’s working pressure: Above 2.5Kg/cm3, that is can work effectively.
Dissolves the gas storage holder: Uses the jet flow type to dissolve is mad the instalment, enters the water air admission basis to dissolve in gas storage holder’s pressure automatic control, no need specialist operates.
Water flow of dissolving air: May act according to the different suspension density or the water body nature adjustment dissolves is mad the water volume.
Equipment material quality and anticorrosion: Equipment internal anticorrosion epoxy coal tar anticorrosion. After exterior uses iron oxide red antirust paint two, spurts from does hammer finish two.
